EV Charger Test & Research Laboratory



  • “EV Charger Test & Research Laboratory” at CPRI, Bengaluru is established for testing and certification purposes.
  • The Laboratory shall be suitable for testing of both AC/ DC electric vehicle (EV) supply equipment (EVSE) or EV Charging station or EV Chargers up to capacity of 22kW(AC) & 50kW(DC).
  • The EVCTR laboratory shall be able to verify the efficiency, output ripples, charging performance, electrical safety performance, EMI EMC, and communication protocols as per the national and international standards covering all charging methodologies viz. CCS, CHAdeMO, GB/T and Bharat chargers.



Major testing standards for EV chargers that can be tested at CPRI, Bengaluru are:

  • IS 17017-1 (IEC 61851-1)
  • IS 17017-23 (IEC 61851-23)
  • IEC 61851-24
  • IS 17017-21-2 (IEC 61851-21-2)
  • IS/ISO 15118-1,-2,-3,-4,-5,-6,-7, and -8
  • IS 17017-2-1 (IEC 62196-1)
  • IS 17017-2-2 (IEC 62196-2)
  • IS 17017-2-3 (IEC 62196-3)
  • Efficiency test as per CPRI test procedure
  • Output ripple test


  • IEC 60068-2-1: Cold test
  • IEC 60068-2-2: Dry heat test
  • IEC 60068-2-14: Change of temperature test
  • IEC 60068-2-30: Damp heat cyclic test
  • IEC 60068-2-78: Damp heat steady-state test
  • IEC 60068-2-64: Vibration test
  • IEC 60529: Ingress protection test
  • IEC 60068-2-52: Salt mist test
  • IEC 60068-2-5: Solar Radiation test





Our division is also engaged in Conducting webinars/ training program/ seminars/ conference/ workshop on standards related to EV Charger testing.
