800 kV IMPULSE TEST LABORATORY

800 kV IMPULSE TEST LABORATORY

MAJOR EQUIPMENTS AVAILABLE IN IMPULSE TEST LAB

1. 800 kV, 80kJ Impulse Generator
2. 800 kV Voltage Divider
3. 800 kV Chopping Gap

IMPULSE TEST FACILITY

Lightning impulse Withstand with chopped wave for Distribution Transformer and Power Transformers upto 10 MVA 33/11kV Class as per IEC 60076-3, IS 2026-3

Lightning impulse Withstand with chopped wave for Dry type Transformer Transformers upto 10 MVA 33/11kV Class as per IEC 60076-11, IS 2026-11

Lightning Impulse withstand for switchgears and disconnectors upto 132kV class as per IEC 62271

   800 kV Impulse Generator                                                 Impulse Lab Control Room
