1500 MVA SHORT CIRCUIT TEST LABORATORY, RTL Nashik

1500 MVA SHORT CIRCUIT TEST LABORATORY

MAJOR EQUIPMENTS AVAILABLE IN 1500 MVA SHORT CIRCUIT LAB

1. Single phase Short Circuit Transformer each of 500 MVA capacity.
2. Circuit Breaker 245 kV, 50 kArms
3. Master Breakers: 400 kV, 63 kArms for 3s
4. Make Switches: 52.0 kV, 80kArms
5. 52 kV Reactors

SHORT CIRCUIT TEST FACILITY

Short circuit Dynamic and Thermal withstand test facility for Distribution Transformer, Power Transformers and Dry type Transformers upto 10 MVA 33/11kV Class. IEC 60076-5, IS 2026-5

  52kV CPRI Switchyard                                                                            Shunts                                    52 kV Make Switch                                                 Short Circuit Control Room

TRANSFORMER ROUTINE TEST LABORATORY

MAJOR EQUIPMENTS AVAILABLE IN ROUTINE TEST LAB

1. Intermediate Transformers 100 KVA
2. 100 kV HV Transformer
3. MG-SET

ROUTINE TEST FACILITY

Routine test facility for Distribution Transformer and Power Transformers upto 10 MVA 33/11kV Class as per IEC 60076-1, IS 2026-1, IS 1180

Routine test facility for Dry Type Transformers upto 10 MVA 33/11kV Class as per 60076-11

             Routine Lab Control Panel                                        100KVA Intermediate Transformers

                   MG-SET                                                                                 Instrument Trolley
